Wheelchair accessible lift
Your outdoor lift is spacious enough to take wheelchairs, walkers and strollers, or groups of up to 5 people.
Vertical Platform lifts
Cibes Outdoor Lift
Elevators for seamless outdoor living
Do you want to make the most of outdoor living? In that case, installing an outdoor lift will provide easy and comfortable access to your garden. The Cibes outdoor lift will resist to almost any weather conditions and because the lift is installed on the outside of your home, you do not need to worry about sacrificing any of your indoor space.
Weather resistant elevator
The lift comes fully equipped to handle most weather conditions and offers options for temperature control.
Ready-made concept
Because all elements are ready-made, your lift is much faster and easier to install than a conventional elevator.
Standard outdoor equipment
The outdoor lift is available in two wheelchair-friendly sizes: 40 x 58″ and 44 x 58″. Your lift includes the following equipment to ensure that it is weather resistant:
- Slanted outdoor roof to protect the lift from rain and snow
- Door canopies in plexiglas or steel
- Rust proof AL5 aluminum doors
- Sealed, weather resistant call buttons
- Sealed glazed shaft panels
- Bottom frame with anti corrosive coating
- Electrical compartment with flooding protection
Your outdoor elevator is designed for a temperature range of approximately 14° to 86°F. For more extreme climates, we offer additional options for temperature control, such as AC ready lifts and heating solutions.
Lift car characteristics
The lift car controls are operated with hold to run operation. You simply maintain pressure on the floor button to travel and release pressure to stop.
Our outdoor lifts have a rated load of 880 lbs (4-5 passengers) and the lift speed is limited to 30fpm, in accordance with regulations.
However, the limited speed also offers advantages. Whereas conventional elevators need big and bulky shaft structures to absorb the forces generated by high speed, the Cibes outdoor lift just needs a prefabricated, space-saving ready-made shaft in steel or glazed panels.
Standard outdoor lift features
Slanted roof
The slanted outdoor roof can be configured to slope in 3 different directions to lead the rain and snow away from the building.
Plexiglas canopy
The elegant door canopy in plexiglas protects all exposed lift doors from light rain and snow, perfect for warm to temperate climates.
Steel canopy
The sturdy door canopy in steel protects all exposed lift doors from heavy rain and snow, which is ideal for cold and rough climates.
Call buttons
To resist in humid conditions, the push button is in stainless steel and has a class IP55 seal. The faceplate in anodized aluminum.
Rust proof aluminum doors
The strong and light-weight AL5 aluminum door is rust proof and the standard door model for our outdoor lifts.
Immaculate finish
No rivets are visible on the inside the shaft. The corner profile includes a cover to hide all rivets, for an immaculate finish.
Sealed glass panels
The glazed panels of the lift shaft are equipped with a rubber seal to prevent water infiltration and reduce condensation.
Additional options
In addition to the standard equipment, we also offer you a wide choice of optional features to optimize the comfort, function and look of your elevator, such as:
- AC ready lift (connection prepared)
- Heating solutions for electronic components
- Snow fence for the roof
- Lift prepared for gutter installation
- Super panoramic AL6 aluminum doors
- Different lock solutions (tag/key/code locks)
- Elegant lighting solutions
- The choice of 250+ RAL colors
Do you want more advice or additional information? Just contact your local Cibes Symmetry dealer, they will be happy to help!
Elegant outdoor lift options
To give your outdoor lift and elegant touch, why not add our super panoramic doors for an exclusive and spectacular look? Another great option is to choose one one of our cool lighting solutions to ensure that your outdoor elevator is beautifully lit also at night time.
LED lit canopy
The LED lit canopy offers you a nice-looking lighting effect as well as a practical, additional light source at night-time.
Safety edges with LED
The safety edges of the platform floor can be equipped with LED strips to create a cool lighting effect.
Super panoramic AL6 door
The slim and elegant AL6 aluminum door looks amazing and makes the most of your panoramic views.
High quality outdoor elevator
To ensure that your lift will operate smoothly regardless of weather conditions, our outdoor elevators are built to withstand the harsh Scandinavian climate, but also sunny and hot weather. In fact, the screw-driven system of our lifts is less sensitive to changes in temperature and humidity than most other drive systems, which is ideal for outdoor conditions.
For extremely hot and cold climates we also offer a range of different solutions. We have done our best to think about everything, but if you need a special solution, just talk to your local dealer and we will do our best to help out.
Weather resistant elevators
Snow, rain or scorching heat – for our lifts there is no bad weather! If you live in a place with challenging weather conditions, just contact us and we will talk you through your options.
Wheelchair accessible
The platform sizes of this lift model are big enough to fit most wheelchairs. However, we recommend you to select the biggest 44 x 58″ size, if your lift doors are placed at a 90° angle, as it will make it easier to turn the wheelchair at exit.
To be on the safe side, always measure your wheelchair before investing in a lift.
- Measure your wheelchair w x d (including wheels and footrest).
- Try to estimate the minimum door width you need.
- Also make sure that you have enough space on the landings to enter and exit.
Design your outdoor lift
Your outdoor elevator will make it easier to access and enjoy your garden but it is also a stylish architectural feature. Check out our wide range of colors and finishes and create your own bespoke lift design!
Installation
In most cases, the outdoor lift is installed against the exterior wall. Although it is possible to install the lift in a masonry shaft there is no need. Our lifts come with a ready-made shaft.
Optimal use of space
An outdoor elevator preserves the available space inside your home, offering you a wide range of possible configurations. Our flexible design can adapt to almost any building.
Glazed elevator shaft
Do you want to enjoy the view from your lift? No problem. We offer fully or partially glazed lift shafts. In fact, we are one of the few who can supply a fully panoramic elevator shaft.
Get creative
Our great choice of colors and finishes makes it possible to customize you lift to match your home and your unique sense of style.
Call button
Gray or white as standard, the call button faceplate is available in any RAL or premium color.
250+ RAL colors
Cibes lifts are available in more than 250 RAL colors. Which color is the perfect fit for your home?
Canopy in plexiglas
The aluminum rims and fixings of the canopy are available in any RAL or premium color.
Cibes Color Guide
Let Cibes color collection inspire you to find the perfect shade for your outdoor elevator. We color you happy.
Specifications and model details
Technical information
- Installation:Outdoor
- Rated load:880 lbs
- Power supply:230 VAC, 60 Hz, 16 AMP, Single-Phase
- Speed:30 FPM
- Min headroom:Depends on lift configuration
- Lift pit:0", 2", or 2 3/4"
- Drive system:Screw and nut
- Max travel:23 ft
- Max number of stops:4
- Lift controls:Hold-to-run
- Motor Power:3 HP
- Machine room:Machine room-less (MRL)
- Door configuration:Single access, Same side, Straight-Through, or 90 degree
Complete specifications and lift sizes
Check out the full Complete specifications and model details of Cibes Outdoor Lift.
